Summary
24 hr production: 850 lb @ 70/50, 700 lb @ 90/70
Dimensions: 22" W x 16.5" D x 29" H
Shipping Carton: 25.5" W x 19.5" D x 34" H
Shipping Weight: 118 lb
Available Condenser Options: Remote Low-Side
Electrical
Base Electrical Ice Head, Volts/Hz/Phase: 115/60/1
Base Electrical Condensing Unit Volts/Hz/Phase: 208-230/60/1
BTU Per Hour: 13,700
Max. Fuse Size Ice Head: 15 amps
Max. Fuse Size Compressor: 20 amps
Circuit Wires: 2
Min. Circuit Ampacity Ice Head: Cord
Min. Circuit Ampacity Condensing Unit: 14.8
Energy & Water Usage
Energy Consumption: 5.2 kWh/100 lb
Water Usage: 18.0 gallons/100 lb
Technical specs are based on remote-cooled model single phase.
Certifications
