Summary
24 hr production: 1425 lb @ 70/50, 1200 lb @ 90/70
Dimensions: 30" W x 24" D x 29" H
Shipping Carton: 34” W x 28” D x 32” H
Shipping Weight: 165 lb / 75 kg
Available Condenser Options: Remote Low-Side
Electrical
Base Electrical Ice Head, Volts/Hz/Phase: 115/60/1
Base Electrical Condensing Unit, Volts/Hz/Phase: 208-230/60/1
BTU Per Hour: 20,000
Max Fuse Size Ice Head: 15 amps
Max Fuse Size Condensing Unit: 30 amps
Circuit Wire: 2
Min. Circuit Capacity Ice Head: Cord
Min. Circuit Ampacity Condensing Unit: 16.5
Energy & Water Usage
Energy: 4.5 kWh/100 lb
Water: 18.0 gallons/100 lb
Technical specs are based on remote-cooled model, single phase.
Certifications
